RCBO
WRCT Double Pole RCBO (Twin Switches)
Two switches on one double-module body, so the residual-current and overcurrent halves can be operated separately — useful when a fault has to be isolated without dropping the whole circuit.
Technical overview
Core specifications
Rated current In6, 10, 16, 20, 25, 32, 40A
PolesDouble pole, double module
Residual current typeA / AC
Rated residual current30, 100mA
Trip characteristicB, C
Breaking capacity Icn10kA
Rated voltage Un240V AC
Electrical endurance4,000 cycles
Mechanical endurance10,000 cycles
Cable terminal capacity16mm² maximum
ConnectionBidirectional
Model selection note Ratings and approval scope vary by configuration.
Include the destination market, application and required rating in your inquiry so sales can match the exact model and documentation.
Product video
See the product and its application.
Short product and application footage to support technical evaluation and specification.
Commercial & documentation
Information purchasing teams expect
Commercial terms are managed by model so purchasing teams can distinguish standard supply, samples and OEM orders.
Sample cost and preparation time are confirmed with the selected model.
Standard and customised orders may use different timelines.
The applicable term is linked to product family, market and supply conditions.
Technical files
Datasheet, dimensions and certificate scope
Technical files are supplied against the selected model so ratings, dimensions and compliance scope remain clear.
PDF · Product datasheet DWG/PDF · Dimensions & installation PDF · Certificate scope
Request Technical Files Typical use
- Circuits needing separate isolation
- Maintenance-heavy installations
- Replacement of twin-switch legacy devices
Compliance references
- BS EN 61009-1
Customisation scope
- Brand marking
- Current and characteristic mix
- Packaging
