Standard, trial-order and OEM quantities can be reviewed separately.
Garage / EV Consumer Unit
Flush Mounted Metal Garage Unit
The recessed version of the steel garage board, same incomer and MCB options.
Technical overview
Core specifications
ModelWFGU
Incomer optionsDP 40A/63A Type A RCD, or DP 100A main switch
Outgoing devices6A–50A MCB
Cable entry25 and 32mm knockouts, top, bottom and sides
Max cable capacity35 mm²
Ingress protectionIP40
InstallationFlush mounted
Model selection note Ratings and approval scope vary by configuration.
Include the destination market, application and required rating in your inquiry so sales can match the exact model and documentation.
Product video
See the product and its application.
Short product and application footage to support technical evaluation and specification.
Commercial & documentation
Information purchasing teams expect
Commercial terms are managed by model so purchasing teams can distinguish standard supply, samples and OEM orders.
Sample cost and preparation time are confirmed with the selected model.
Standard and customised orders may use different timelines.
The applicable term is linked to product family, market and supply conditions.
Technical files
Datasheet, dimensions and certificate scope
Technical files are supplied against the selected model so ratings, dimensions and compliance scope remain clear.
PDF · Product datasheet DWG/PDF · Dimensions & installation PDF · Certificate scope
Request Technical Files Typical use
- Garages and outbuildings
- Utility rooms
- Sub-distribution
Compliance references
- BS EN 61439-3
- CE · UKCA
Customisation scope
- Enclosure marking
- Populated device configuration
- Project packaging
