Surge Protectors
WST-N Surge Protective Device
The Type 1+2 range configured for a T/T system, where the neutral has to be protected against the earth rather than treated as a reference. A gas discharge tube sits in the N-PE path and the remaining poles carry the varistor modules, so a 1P+N device is one tube and one varistor rather than two of a kind.
Technical overview
Core specifications
TypeType 1+2
Poles1P+N, 3P+N
SystemT/T, with N-PE protection
Rated voltage Uc320V AC on the line poles · 255V AC on the N-PE module
N-PE moduleGas discharge tube, no In or Imax rating of its own
Lightning impulse current Iimp (T1)12.5kA, 10/350us
Nominal discharge current In (T2)30kA, 8/20us on the line poles
Maximum discharge current Imax (T2)60kA, 8/20us on the line poles
Voltage protection level UpUp to 2.0kV
Operating temperature-40 to +80 degrees C
Protection classIP20
Dimensions89.6 x 71.7 x 80.8mm (3P+N), 35mm DIN rail
Model selection note Ratings and approval scope vary by configuration.
Include the destination market, application and required rating in your inquiry so sales can match the exact model and documentation.
Product video
See the product and its application.
Short product and application footage to support technical evaluation and specification.
Product video available on request
A product video for this model is being prepared. Contact sales to request current product or application footage.
Request product video → Commercial & documentation
Information purchasing teams expect
Commercial terms are managed by model so purchasing teams can distinguish standard supply, samples and OEM orders.
Sample cost and preparation time are confirmed with the selected model.
Standard and customised orders may use different timelines.
The applicable term is linked to product family, market and supply conditions.
Technical files
Datasheet, dimensions and certificate scope
Technical files are supplied against the selected model so ratings, dimensions and compliance scope remain clear.
PDF · Product datasheet DWG/PDF · Dimensions & installation PDF · Certificate scope
Request Technical Files Typical use
- T/T installations at the service entrance
- Residential and light commercial main boards
- Sites with an external lightning protection system
Compliance references
- IEC / EN 61643-11
- CE · UKCA marked on the product
Customisation scope
- Marking
- Packaging
- Pole assortment
